ÖlofBlue High Flow Pleated Filter Cartridges utilize pleated depth media and result in exceptional flow capacity, low pressure drop and excellent retention efficiency. The considerate design of top handle makes manual operation quick and easy. Extended service life and less maintenance requirement make the filter cartridges as one of the most cost-saving solutions in big RO applications.

Features

  • High surface area results in longer service life, lower pressure drop and higher flow capacity.
  • The considerate design of top handle makes change out quick and easy.
  • Extended service life and less maintenance requirement make the cartridges as one of the most cost saving solutions.
  • Available in various sizes and filter media to meet different needs and applications.
  • Free of additives and binders due to advanced thermally welding construction.

Standard Applications

  • Chill water loop filtration
  • Food & Beverage filtration
  • Marine/Aquatic filtration
  • Membrane Protection
  • Commercial drinking water filtration
  • Desalination pre-filtration
  • Reverse Osmosis pre-filtration
  • Cooling tower filtration
  • Chemicals
  • Electronics
  • Petrochemicals
ÖlofBlue HF Series

Operation Data


Maximum Operating Temperature
Polypropylene
82°C (180°F)
Glass Fiber
121°C (250°F)
Polyethersulfone
82°C (180°F)
Maximum Differential Pressure
Recommended Change Out Differential Pressure
3.4 bar at 25°C (50 psi at 77°F), 2.2 bar at 82°C (33 psi at 180°F)
2.2 bar (33 psi)

Ordering information

Type
PB - Melt Blown Filter Cartridge
GD - PP Fiber Pleated Filter Cartridge
Rating (μm)
001 - 0.1 μm
002 – 0.2 μm
0H – 0.45μm
010 – 1 μm
020 – 2 μm
050 – 5 μm
100 – 100 μm
Media
P - Polypropylene
S- Polyethersulfone
G – Glass Fiber
Length
20 – 20"
40 – 40"
60 – 60"
Other Customized Sizes
End Cap
Blank – Open End
N – Sealed End
O-Ring
S-Silicone
E-EPDM
V-Viton
W-Teflon encapsulated Viton
